ArgoCD on EKS: GitOps Continuous Delivery for Kubernetes

GitOps is the practice of using a Git repository as the single source of truth for what should run in your Kubernetes cluster. ArgoCD implements this by watching a Git repo, comparing its contents against the live cluster state, and automatically reconciling any drift. A developer pushes a change to a Helm chart or Kubernetes manifest; ArgoCD sees the change within minutes and applies it to the cluster. No kubectl commands in CI pipelines, no deploy scripts, no “what version is running in production?” questions.

This guide covers installing ArgoCD on EKS, defining applications, configuring automated sync with safety controls, managing multiple environments with ApplicationSets, RBAC for team access control, and integrating with GitHub Actions.

Installing ArgoCD on EKS

# Create a dedicated namespace
kubectl create namespace argocd

# Install ArgoCD (latest stable)
kubectl apply -n argocd \
  -f https://raw.githubusercontent.com/argoproj/argo-cd/stable/manifests/install.yaml

# Wait for all pods to be ready
kubectl wait --for=condition=available deployment \
  --all -n argocd --timeout=300s

# Check pod status
kubectl get pods -n argocd

By default, ArgoCD uses a ClusterIP service. For EKS production use, expose it through an ALB with AWS Load Balancer Controller:

# argocd-ingress.yaml
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: argocd-server-ingress
  namespace: argocd
  annotations:
    kubernetes.io/ingress.class: alb
    alb.ingress.kubernetes.io/scheme: internal
    alb.ingress.kubernetes.io/target-type: ip
    alb.ingress.kubernetes.io/backend-protocol: HTTPS
    alb.ingress.kubernetes.io/listen-ports: '[{"HTTPS":443}]'
    alb.ingress.kubernetes.io/certificate-arn: arn:aws:acm:us-east-1:123456789012:certificate/abc-123
    alb.ingress.kubernetes.io/ssl-policy: ELBSecurityPolicy-TLS13-1-2-2021-06
spec:
  rules:
    - host: argocd.internal.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: argocd-server
                port:
                  number: 443

kubectl apply -f argocd-ingress.yaml

# Get the initial admin password
kubectl -n argocd get secret argocd-initial-admin-secret \
  -o jsonpath="{.data.password}" | base64 -d

# Login with argocd CLI
argocd login argocd.internal.example.com \
  --username admin \
  --password $(kubectl -n argocd get secret argocd-initial-admin-secret -o jsonpath="{.data.password}" | base64 -d)

# Change the admin password immediately
argocd account update-password

Defining Applications

An ArgoCD Application is a CRD that maps a Git repository path to a cluster namespace.

# my-api-app.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: my-api
  namespace: argocd
  finalizers:
    - resources-finalizer.argocd.argoproj.io  # Cascade delete resources on app deletion
spec:
  project: default
  source:
    repoURL: https://github.com/myorg/k8s-manifests.git
    targetRevision: HEAD
    path: apps/my-api/overlays/production
  destination:
    server: https://kubernetes.default.svc  # This cluster
    namespace: my-api
  syncPolicy:
    automated:
      prune: true       # Delete resources removed from Git
      selfHeal: true    # Revert manual kubectl changes
      allowEmpty: false # Prevent syncing empty state (safety)
    syncOptions:
      - CreateNamespace=true
      - PrunePropagationPolicy=foreground
      - PruneLast=true
    retry:
      limit: 5
      backoff:
        duration: 5s
        factor: 2
        maxDuration: 3m

kubectl apply -f my-api-app.yaml

# Or create via CLI
argocd app create my-api \
  --repo https://github.com/myorg/k8s-manifests.git \
  --path apps/my-api/overlays/production \
  --dest-server https://kubernetes.default.svc \
  --dest-namespace my-api \
  --sync-policy automated \
  --auto-prune \
  --self-heal

# Check sync status
argocd app get my-api
argocd app sync my-api  # Manual trigger if automated is off

prune: true deletes Kubernetes resources when you remove them from Git. Without it, removed manifests leave orphaned resources in the cluster. Enable it for production — the alternative is accumulating zombie deployments and services.

selfHeal: true reverts manual cluster changes. If someone runs kubectl scale deployment my-api --replicas=5 directly, ArgoCD resets it back to whatever the Git manifest specifies within minutes. This enforces Git as the only path to change cluster state — which is the whole point of GitOps.

Helm Chart Applications

# my-api-helm.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: my-api-helm
  namespace: argocd
spec:
  project: default
  source:
    repoURL: https://github.com/myorg/helm-charts.git
    targetRevision: v1.5.2
    path: charts/my-api
    helm:
      releaseName: my-api
      valueFiles:
        - values/production.yaml
      parameters:
        - name: image.tag
          value: "2.1.4"
        - name: replicaCount
          value: "3"
  destination:
    server: https://kubernetes.default.svc
    namespace: my-api
  syncPolicy:
    automated:
      prune: true
      selfHeal: true

Pinning targetRevision to a Git tag (v1.5.2) rather than HEAD means ArgoCD only syncs when you deliberately cut a new release — not on every commit. For production environments, tag-based tracking is safer than branch tracking. For staging, HEAD of a branch is fine.

App of Apps Pattern

For many applications, define a “root” application that manages other ArgoCD applications:

# root-app.yaml
apiVersion: argoproj.io/v1alpha1
kind: Application
metadata:
  name: root
  namespace: argocd
spec:
  project: default
  source:
    repoURL: https://github.com/myorg/k8s-manifests.git
    targetRevision: HEAD
    path: argocd/applications
  destination:
    server: https://kubernetes.default.svc
    namespace: argocd
  syncPolicy:
    automated:
      prune: true
      selfHeal: true

The argocd/applications directory in Git contains Application manifests for all your services. Adding a new application is a Git commit to that directory. The root app picks it up and creates the child Application automatically. Deleting an Application manifest from Git removes the app (and all its resources if prune: true).

ApplicationSets for Multi-Environment

ApplicationSet generates multiple Application objects from a single template, driven by generators:

# appset-environments.yaml
apiVersion: argoproj.io/v1alpha1
kind: ApplicationSet
metadata:
  name: my-api-environments
  namespace: argocd
spec:
  generators:
    - list:
        elements:
          - env: staging
            cluster: https://staging-cluster.example.com
            namespace: my-api-staging
            imageTag: latest
          - env: production
            cluster: https://prod-cluster.example.com
            namespace: my-api-production
            imageTag: "2.1.4"
  template:
    metadata:
      name: "my-api-"
    spec:
      project: default
      source:
        repoURL: https://github.com/myorg/helm-charts.git
        targetRevision: HEAD
        path: charts/my-api
        helm:
          releaseName: my-api
          parameters:
            - name: image.tag
              value: ""
            - name: environment
              value: ""
      destination:
        server: ""
        namespace: ""
      syncPolicy:
        automated:
          prune: true
          selfHeal: true

This creates my-api-staging and my-api-production Applications from a single definition. A Git generator variant reads environment definitions from files in the repo, so adding a new environment is a Git commit rather than editing the ApplicationSet.

RBAC and Projects

ArgoCD Projects scope what a team can deploy and where:

# Create a project that restricts the platform team
argocd proj create platform-team \
  --description "Platform team applications" \
  --src https://github.com/myorg/k8s-manifests.git \
  --dest https://kubernetes.default.svc,platform-* \
  --allow-cluster-resource Namespace \
  --allow-namespaced-resource "*/*"

# Grant a group access to the project
argocd proj role create platform-team developer
argocd proj role add-policy platform-team developer \
  -a get -a sync -a override \
  -p applications \
  -o "platform-team/*"

# Create an API token for CI/CD (scoped to specific app)
argocd proj role create-token platform-team developer

Projects restrict:

Source repos: teams can only deploy from their approved repos
Destination clusters and namespaces: teams can only deploy to their namespaces
Resource types: limit which Kubernetes resource types a team can manage

The RBAC policy in argocd-rbac-cm ConfigMap controls what roles can do:

kubectl edit configmap argocd-rbac-cm -n argocd

data:
  policy.csv: |
    p, role:developer, applications, get, */*, allow
    p, role:developer, applications, sync, */*, allow
    p, role:developer, applications, action/*, */*, allow
    g, myorg:platform-team, role:developer
  policy.default: role:readonly
  scopes: '[groups]'

OIDC / SSO Integration

For EKS teams using AWS IAM Identity Center, configure ArgoCD OIDC against the IAM Identity Center OIDC endpoint:

kubectl edit configmap argocd-cm -n argocd

data:
  url: https://argocd.internal.example.com
  oidc.config: |
    name: AWS SSO
    issuer: https://identitycenter.amazonaws.com/ssooidc/d-1234567890
    clientID: argocd-client-id
    clientSecret: $oidc.aws-sso.clientSecret
    requestedScopes:
      - openid
      - profile
      - email
    requestedIDTokenClaims:
      groups:
        essential: true

After OIDC setup, groups from IAM Identity Center map to ArgoCD RBAC roles. Team members log into ArgoCD with their SSO credentials rather than individual ArgoCD accounts.

GitHub Actions Integration

Trigger ArgoCD image updates from GitHub Actions after a successful build:

# .github/workflows/deploy.yml
name: Build and Deploy

on:
  push:
    branches: [main]

jobs:
  build:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Build and push Docker image
        run: |
          docker build -t 123456789012.dkr.ecr.us-east-1.amazonaws.com/my-api:$ .
          aws ecr get-login-password | docker login --username AWS --password-stdin 123456789012.dkr.ecr.us-east-1.amazonaws.com
          docker push 123456789012.dkr.ecr.us-east-1.amazonaws.com/my-api:$

      - name: Update image tag in Git manifests
        run: |
          git config user.email "[email protected]"
          git config user.name "GitHub Actions"

          # Update the image tag in the Helm values file
          sed -i "s/tag: .*/tag: $/" helm/my-api/values/staging.yaml

          git add helm/my-api/values/staging.yaml
          git commit -m "chore: update my-api image to $"
          git push
        env:
          GITHUB_TOKEN: $

The CI pipeline builds and pushes the image, then updates the Git manifest with the new image tag. ArgoCD detects the manifest change and syncs the cluster. This is the GitOps pattern: CI pushes to Git; ArgoCD pulls from Git to the cluster. The cluster never exposes kubectl access to CI — it only needs Git access.

For the cluster this runs on, the EKS networking VPC CNI guide covers pod networking configuration, and the EKS RBAC and security guide covers how ArgoCD’s service account permissions integrate with EKS IAM roles for service accounts. For Helm charts that ArgoCD deploys, the Helm Charts on EKS guide covers chart structure and values management across environments.
