Many people don’t know that running a graphical application inside a docker container, such as Spotify, is possible. Maybe they never think about it or need to test one application without installing or have more than one installed on the computer. Let’s learn how to run Spotify in Docker Container.
Why Run Spotify on Docker?
Sometimes, I don’t want to install several dependencies on my operation system. So, I love running applications with Docker, so I don’t need to install most of my applications even if I format my computer. And if I need to test a new application, it’s pretty easy.
How it works
However, if you have decided to run by ordinary docker command, then it won’t work. And the reason is that the Docker container is just CLI-based and requires a physical screen to run a GUI application. So for running a graphical application inside a container, we demand to share the base host’s display with the container.
And it is pretty straightforward to do; nevertheless, to understand that command, and you first need to understand two things:
- X server or X11
- The DISPLAY Environment Variable
DISPLAY – Environment Variable
The DISPLAY Environment Variable is the most crucial environment variable for X Window System clients is DISPLAY. When you log in at an X terminal, the DISPLAY environment variable in each xterm window is configured to your X terminal’s hostname followed by: 0.0.
An example of the value of the DISPLAY environment variable:
- hostname is the name of the computer where the X server runs. If this value is omitted, it means localhost.
- N is a sequence number (typically 0). It can be different if there are many displays attached to one computer.
- D is the screen number. A display can have many screens. Typically, there’s only one screen, though where 0 is the default.
What Does X Server Mean?
The x server program connects X terminals running on the X Window System, whether locally or in a distributed network. The X server is installed with the X Window System, a cross-platform and complete client-server system for controlling graphical user interfaces on an individual computer or networked ones. The X server handles the X clients and manages input and display devices, and performs requested operations. This simplifies programming, as the application programs do not need to be aware of the hardware details and rely entirely on the X server.
Presently that we understand both theories, it’s time to execute them. And we will do a fantastic project here. We will run a Spotify application inside the container. Isn’t it amazing?
Dockerfile for Spotify
To run the Spotify in Docker Container, we need a Dockerfile, to build an image first. So below is the Dockerfile to generate an image that you can copy, and it is pretty easy to understand.
FROM ubuntu:18.04 LABEL maintainer "Cleber Rodrigues <email@example.com>" RUN apt-get update && apt-get install -y \ dirmngr \ gnupg \ --no-install-recommends \ && apt-get update && apt-get install -y \ apulse \ libasound2 \ libgl1-mesa-dri \ libgl1-mesa-glx \ libpulse0 \ sudo curl ca-certificates \ --no-install-recommends RUN curl -sS https://download.spotify.com/debian/pubkey.gpg | sudo apt-key add - RUN echo "deb http://repository.spotify.com stable non-free" | sudo tee /etc/apt/sources.list.d/spotify.list RUN sudo apt-get update && sudo apt-get -y install spotify-client && rm -rf /var/lib/apt/lists/* ENV LANG en-US COPY local.conf /etc/fonts/local.conf COPY entrypoint.sh /usr/bin/startspotify ENTRYPOINT [ "startspotify" ]
If you don’t want to build your image, you can use my image available on the Docker Hub.
docker pull bitslovers/spotify:v1
Run Spotify in Docker using x11docker
x11docker allows running graphical desktop applications (and whole desktops) in Linux containers.
You may need to deploy desktop applications with Docker, but it does not typically have a display server for running desktop applications. Also, the X11 Docker allows running desktop applications and even entire desktop in Docker Linux containers. It runs an X display server on the host system and provides it to Docker containers. It additionally does some security setup, which enhances container isolation and avoids X security leaks.
To run Spotify in Docker Container, it’s not required to use the x11docker, however, x11docker makes this process easier.
Installing x11docker on Linux
x11docker requires bash, Docker, and an X server, possibly already installed in your system. This usually is Xorg or Xwayland. You can install a supported base for your distribution, which is intended to give you excellent usage of x11docker.
Note: x11docker works on Linux and (with some setup and restrictions) on M.S. Windows. x11docker does not run on macOS saving in a Linux using a Virtual Machine.
Installing x11docker on Linux
Install x11docker dependencies on Debian|Linux Mint|Ubuntu:
sudo apt-get update sudo apt-get -y install xpra xserver-xephyr xinit xauth xclip x11-xserver-utils x11-utils
# Using sudo
curl -fsSL https://raw.githubusercontent.com/mviereck/x11docker/master/x11docker | sudo bash -s -- --update
# Using root
curl -fsSL https://raw.githubusercontent.com/mviereck/x11docker/master/x11docker | bash -s -- --update
Running Spotify in Docker Container
sudo x11docker --home=/data/spotify --pulseaudio --gpu -- --hostname=spotify spotify:v1
- –home, it’s the location where I decide to store all data for Spotify, like a cache. For example, if I download music, all files are saved on the /data/spotify. So, when you execute Spotify on Docker again, you will keep your data and not require logging in again.
- –pulseaudio. PulseAudio is a general-purpose sound server designed to run as middleware within your applications and hardware devices, either ALSA or OSS. So, it enables the Audio to run Spotify on Docker.
- –gpu. Enable Hardware acceleration for OpenGL to run Spotify on Docker
So finally, when you run the above command, you will launch your container and run the Spotify application.
Run Spotify Quickly from Terminal
To be faster to open Spotify on Docker, I have created Alias on my ~/.bashrc, like this one:
dspotify='sudo x11docker --home=/data/spotify --pulseaudio --gpu -- --hostname=spotify spotify:v1'
Now relax, have a cup of coffee, and appreciate your favorite music.
Conclusion and Goal
It’s not just about Spotify. The great thing about this approach, that force us to understand important features of Linux or Unix and how the operating system works behind the scene.
During this process, I have learned a lot about Docker too. After this article, you will notice that it’s possible to run any application inside Docker, with no limitation.
This technic is very useful for Web Developers to run different web browsers, for example, Google Chrome inside the Docker. For example, something needs to test our application on a different browser, so with Docker, it’s easy to switch between different versions of Google Chrome without installing it on your computer.
I hope that you enjoy this article and that you have learned a lot. Until, next time bitslovers!
